Graphic LCD Module for Portable Medical Devices

Availability:

Quantity:



Application scenarios: CNC machine tool operation panel, PLC controller status display, frequency converter panel, testing and measuring instruments (such as oscilloscopes, multimeters), smart meters/water meters/gas meters, auxiliary display of industrial touch screens.
Inquire Add to Basket

Feature Description

Specification information

Application fields

FAQ

Download

1. Characteristic description

Medical-Grade Display Clarity

Positive display mode (dark text on light background) reduces eye strain for medical staff, even during long shifts.

128x64 resolution clearly shows parameters (e.g., blood glucose levels, heart rate) and simple waveforms (ECG traces).

Ultra-Low Power for Portability

ST7565R driver IC minimizes power consumption to <8mA during operation, extending battery life of portable devices by 0% compared to standard LCDs.

3.3V power supply matches most medical device batteries, avoiding voltage conversion losses.

Compact & Lightweight

Overall dimensions (71.3mm X 52mm X 5.1mm) and lightweight structure (15g) fit into slim medical devices (e.g., blood oxygen monitors).

PITCH 0.5*36PIN plug-in interface saves PCB space, enabling smaller device enclosures.

2. Performance meets

Reliability for Medical Standards

Undergoes 1000-hour high-temperature (+70℃) and low-temperature (-20℃) testing, ensuring stable performance in clinics and homes.

Resists electromagnetic interference from other medical equipment (e.g., MRI machines), avoiding display glitches.

Easy Integration & Customization

Supports 8080/4L_SPI interfaces, compatible with medical-grade MCUs (e.g., NXP LPC series).

Offers custom backlight brightness (300–500 CD/M2) for different lighting conditions (e.g., bright clinics, dim bedrooms).

The G260 module has a model number of G260, with a lattice number of 12864. Its display type is STN, and the viewing angle is 6 O’Clock. It supports 8080/4L_SPI interfaces and uses the ST7565R driver IC. The overall dimensions are 71.3mm X 52mm X 5.1mm, and the VA area size is 65mm X 38mm. It runs on a 3.3V power supply voltage, featuring a positive display mode with full transparency. Its structure combines LCD and BL (backlight), and the connection method uses PITCH 0.536PIN plug-in. The backlight circuit includes 3 LEDs, with a forward current (If) of 45mA and a forward voltage (Vf) of 3V.

Product specification information
Model	G260
Lattice number	128*64
Display type/perspective	STN\| 6 O’CLOCK
Interface	8080/4L_SPI
Drive IC	ST7565R
Overall dimensions	71.3mm X 52mmX 5.1mm
VA area size	65mm X38mm
Power supply voltage	3.3V
Display mode	Positive display, full transparency
Structure	LCD+BL
Connection method	PITCH 0.5 * 36PIN plug-in
Backlight circuit	3LED If=45mA, Vf =3V

Personal Healthcare Devices

Blood glucose meters: Displays glucose levels, test times, and average values.

Electronic blood pressure monitors: Shows systolic/diastolic pressure and heart rate.

Blood oxygen saturation monitors: Visualizes SpO2 levels and pulse rates.

Graphic LCD Module for Portable Medical Devices

Professional Medical Equipment

Portable ECG machines: Displays 3-lead ECG waveforms and heart rate data.

Infusion pump display interfaces: Shows flow rate, remaining volume, and alarm status (e.g., occlusion).

Does the G260 meet medical device certifications?

Yes. The module complies with RoHS and REACH standards. We also provide documentation to support ISO 13485 and FDA 510(k) certifications for customer devices.

Can the backlight be turned off to save power?

Yes. The backlight has a software-controlled on/off function, ideal for devices used in low-light environments (e.g., night-time home monitoring).

What is the display's response time?

Typical response time is 100ms, sufficient for displaying static physiological data (e.g., blood pressure) and slow-changing waveforms (e.g., ECG).
